Milesight UC511 Solenoid Valve Controller
Authorised Milesight UK DistributorPrice range: £119.71 through £131.68 ex VAT (£143.65 – £158.02 inc. VAT)
UC511 is a LoRaWAN solenoid valve controller with two M12 interfaces for 2-wire DC 12V latching solenoids plus two digital inputs. Its decisive difference from UC512 is the power supply: embedded solar power (6V, 1.7W) with 2 × 2550 mAh ICR18650 chargeable batteries, instead of replaceable lithium cells. The enclosure is IP68, rated 1 m underwater for seven days.
Power SupplyEmbedded solar power (6V, 1.7W) plus 2 × 2550 mAh ICR18650 chargeable batteries — UC512 instead uses 3 × 9000 mAh replaceable ER26500 Li-SOCl2 batteries
In stock · typically dispatched within 14 working days from the UK
● Quotes answered within one working day · UK support
Delivery & assurance
- Ships from the UK
- £14.25 flat UK delivery
- Secure checkout — card, Klarna, invoice
- Manufacturer's warranty
Questions about this product? Call our UK team: 023 9223 3611
Description
PS51x series LoRaWAN® Solenoid Valve
Controller is a device used to remotely
control DC latching solenoid valves. It
contains 2 solenoid interfaces and 2 GPIO
interfaces, which can be easily controlled
locally or remotely.
Besides ultra-low-power LoRaWAN®
technology, 51x series also provides built-in
solar panel or a high-capacity battery power
supply for long-term operation.
For outdoor applications, it has an IP67-
rated enclosure and M12 connectors to
protect from water and dust under harsh
environments.
Features
- Supplied with standard DC latching solenoids.*
- OPEN/CLOSE control by mobile App locally or commands remotely.
- TwoGPIO interfaces for flow monitoring or valve status monitoring.
- Transmission distance up to 15 km with line of sight.
- Industrial design including IP67 case and M12 connectors.
- Solar powered and built-in chargeable battery.
- Quick wireless configuration via NFC.
- Time and flow control via IoT Cloud with full remote operation.
Additional information
| Weight | 0.425 kg |
|---|
UC511-DI specifications
| Solenoid Interface Ports | 2 × Solenoid Interfaces, M12 A-Coded Male |
|---|---|
| Solenoid Support | 2 Wires DC 12V Latching Solenoids |
| Cable Length | 1.5 m (by default) |
| GPIO Interface | 2 × Digital Inputs; work mode Digital Input or Pulse Counter |
| GPIO Logical Level | Low: 0~0.8 V, High: 2.5~3.3 V; maximum current 20 mA |
| Input Frequency | Suggested value: ≤4000 Hz |
| Pressure Collection Interface (AI Version Only) | M12 A-Coded Male; supports PS02 and PS03 pressure sensors |
| Optional Pressure Sensor | PS02/PS03: gauge pressure 0~1600 kPa (16 Bar), accuracy ±0.5% FS, resolution 1 kPa, overload 200% FS, G 1/2" process connection |
| Wireless Transmission Technology | LoRaWAN, Milesight D2D |
| Frequency | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4 |
| Tx Power / Sensitivity | 16dBm (868 MHz) / -137dBm @300bps |
| Working Mode | OTAA/ABP Class A, Class B, Class C, Class C to B |
| Antenna | Internal Antenna or External Antenna (hardware optional); EA version: 1 × 50 Ω SMA female connector |
| Power Supply | 1. Embedded Solar Power (6V, 1.7W); 2. 2 × 2550 mAh ICR18650 chargeable batteries; 3. DC 5-24 V by power connector (EA version only) |
| Battery Life (20 min interval + control valve 4 times per day, 25°C) | Battery full and not charging — Class A: around 8.4 years (SF7), around 3.3 years (SF10); Class B: around 1.1 year; Class C: around 26 days |
| Advanced Feature | Multicast, Milesight D2D Agent, Local Rules, Water Pressure Alarm; FUOTA firmware update over the air |
| Configuration | Mobile App via NFC; power on/off by NFC app, internal power button or cable connection |
| Operating Temperature | -20°C ~ 60°C; relative humidity 0 ~ 95% (non-condensing) |
| Ingress Protection | IP68 (1 m underwater, 7 days) |
| Dimensions / Weight | 116 × 116 × 45.5 mm (4.56 × 4.56 × 1.79 in, connectors excluded); IA version 425 g, EA version 467 g with batteries; wall or pole mounting |
Specifications taken from the manufacturer datasheet.
Which version do I need?
868M denotes the EU868 LoRaWAN band, correct for the UK; the datasheet lists CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4. The datasheet documents four hardware variants of UC511: UC511 (internal antenna), UC511(EA) with an external SMA antenna and an M12 DC 5-24 V power connector, UC511(AI) with the pressure collection interface, and UC511(EA-AI) with both. A plain UC511-868M part number carries neither the external antenna nor the AI pressure interface.
Typical applications for the UC511-DI
- Agriculture valve control
- Landscape irrigation systems
- Garden irrigation systems
- Remote OPEN/CLOSE valve control over LoRaWAN
- Irrigation water pressure monitoring (AI version)
- Flow monitoring or valve status monitoring via the GPIO pulse counter
Buying guides for this product
Frequency band
Supplied on EU868, the LoRaWAN band used in the UK and across Europe. That is the default and you do not need to ask for it — the -868M in the part number is the EU868 build.
The same UC511-DI unit also covers IN865 and RU864. Those bands share the 863–870 MHz radio with EU868, so one device can be set to any of them in its own configuration — no different part number needed.
CN470, US915, AU915, KR920 and AS923 are a different radio and therefore a different build. Milesight makes them and we can order them: tell us where the devices are being deployed and we will confirm the part number, price and lead time.
Not sure which band applies where? The Things Network publishes the LoRaWAN frequency plan for every country.
Complete the stack
Products that work with this one — connect it, power it, and get it online.
Which gateway do I need? Compare the Milesight range, from £98.76 →
-
-
Milesight TS201 Temperature Sensor
TS201 Price range: £44.89 through £52.37 ex VAT (£53.87 – £62.84 inc. VAT)Select options This product has multiple variants. The options may be chosen on the product page -
Milesight TS302 Temperature Sensor
Price range: £64.34 through £73.32 ex VAT (£77.21 – £87.98 inc. VAT)Select options This product has multiple variants. The options may be chosen on the product page -
UC511-DI — frequently asked questions
What solenoids does the UC511 drive?
Two 2-wire DC 12V latching solenoids, connected on two M12 A-coded male solenoid interfaces with 1.5 m cables by default.
Does the UC511 need mains power?
No. It runs from embedded solar power (6V, 1.7W) charging 2 × 2550 mAh ICR18650 batteries. Only the EA (external antenna) version adds a DC 5-24 V input on its M12 power connector.
How long does it run if the solar panel does not charge?
With a full battery and no charging, at a 20-minute interval and four valve operations a day at 25°C: Class A around 8.4 years at SF7 or 3.3 years at SF10, Class B around 1.1 year, Class C around 26 days.
Can the UC511 monitor water pressure?
Only the AI version, which adds a pressure collection interface supporting the PS02 and PS03 sensors — gauge pressure 0~1600 kPa (16 Bar), ±0.5% FS accuracy, 1 kPa resolution — with water pressure threshold alarms.
How does UC511 differ from UC512?
UC511 is solar-powered with rechargeable ICR18650 cells, supports Milesight D2D, and works in Class A, B, C and C-to-B. UC512 uses 3 × 9000 mAh replaceable ER26500 Li-SOCl2 batteries, is LoRaWAN only, and supports Class A and Class B.
How much does the Milesight UC511 Solenoid Valve Controller cost in the UK?
The Milesight UC511 Solenoid Valve Controller starts at £119.71 ex VAT from Indiott, with the exact figure depending on the variant you choose. Indiott is a UK distributor and invoices with VAT (PSI Technologies Ltd, VAT GB 730 2340 83). UK delivery is a flat £14.25 per order ex VAT, whatever the weight.
What is the lead time and delivery cost for the Milesight UC511 Solenoid Valve Controller?
The Milesight UC511 Solenoid Valve Controller is in stock and typically dispatched within 14 working days from the UK. UK delivery is a flat £14.25 per order ex VAT, whatever the weight or how many items you order. We ship to GB and the EU and provide a VAT invoice with every order.
