ATOP EH2005 Industrial Unmanaged Ethernet Switch
Request a price
The EH2005 is an ATOP unmanaged industrial Ethernet switch with 5 ports: four 10/100BaseT(X) copper ports plus one fibre port (SFP, LC or ST). Use it in a DIN-rail cabinet where a small group of field devices needs connecting and one link must run over fibre. Operating temperature 0~60°C, IP30, 9~30 V input.
Total number of ports (port mix)5 ports - 4 x 10/100BaseT(X) copper plus 1 fibre port (SFP, LC or ST)
● Quotes answered within one working day
Available to order · request a quote for price and lead time
Delivery & assurance
- Ships from the UK
- UK & EU delivery, quoted with your price
- Pay by card or invoice
- Manufacturer's warranty
Questions about this product? Call our UK team: 023 9223 3611
Description
The EH2005 Series features a 5-port Ethernet switches with 4 x RJ-45 ports and one optic ST/SC port for your industrial applications. The EH2005 series has been designed for industrial environments, such as in hazardous locations, where it complies with FCC, TUV, UL, and CE standards.
The EH2005 Series protects itself from receiving too many broadcast packets. During normal use, broadcast packets will be forwarded to all ports except the source port. However, EH2005 will discard broadcast or multicast packets if the number of those packets exceeds a threshold in a preset period of time. When the preset period expires (about 800ms), it will then resume receiving broadcast or multicast packets until the threshold is reached again.
The EH2005 Series provides two redundant power inputs that can be connected simultaneously to wide-range DC power sources. If one of the power inputs fails, the other live source acts as a backup to provide the EH series’ power needs automatically.
EH2005 specifications
| Switch type | Unmanaged |
|---|---|
| Total number of ports | 5 |
| Fast Ethernet 10/100BaseT(X) | 4 |
| Fast Ethernet fibre ports (SFP, LC or ST) | 1 |
| PoE/PoE+ ports | None |
| Power input | 9~30 V |
| Power redundancy | Supported |
| Relay output | None |
| Housing | Plastic |
| Installation | DIN-Rail |
| Ingress protection | IP30 |
| Dimensions (L x W x H) | 45 x 90 x 80 mm |
| Operating temperature | 0~60° C |
| Storage temperature | -40~60° C |
| Compliance | UL/EN/IEC(CB) 60950-1 and/or 62368-1; EN60950-1 and/or EN62368-1 |
| Management protocols | None (no SNMP, VLAN, QoS, STP/RSTP or IGMP) |
Specifications taken from the manufacturer datasheet.
Which version do I need?
The EH2005 and EH2006 share one ATOP datasheet and differ only in port mix: the EH2005 gives you 4 copper ports plus 1 fibre port, the EH2006 gives you 6 copper ports and no fibre. Choose EH2005 only if you need the fibre link. The aluminium-housed EH2305 is the same 4-copper-plus-1-fibre layout with a wider -10~70°C operating range.
Complete the stack
Products that work with this one — connect it, power it, and get it online.
EH2005 — frequently asked questions
How many ports does the EH2005 have?
Five in total: four 10/100BaseT(X) copper ports and one fibre port, which can be SFP, LC or ST.
Does the EH2005 support PoE?
No. ATOP's selection guide lists no PoE or PoE+ ports on the EH2005, so powered devices such as IP cameras will need a separate injector or a PoE switch.
Is it a managed switch?
No, it is unmanaged. The EH2005 is listed with no SNMP, VLAN, QoS, STP/RSTP or IGMP support, so there is nothing to configure - it is plug and forward.
What power supply does it need?
A 9~30 V supply. Redundant power input is supported, so a second supply can be wired in for resilience.
Can I install the EH2005 outdoors?
Not directly. It is rated IP30, which offers protection against solid objects only and no water ingress rating, so it must go inside a cabinet or enclosure. The operating range is 0~60°C.
