ATOP EH2006 Industrial Unmanaged Ethernet Switch
Request a price
The EH2006 is an ATOP unmanaged industrial Ethernet switch with 6 ports, all 10/100BaseT(X) copper and no fibre port - that is what separates it from the 5-port EH2005. It mounts on DIN rail in a control cabinet, takes 9~30 V with redundant input, operates 0~60°C and is rated IP30.
Total number of ports6 ports, all 10/100BaseT(X) copper (no fibre port)
● Quotes answered within one working day
Available to order · request a quote for price and lead time
Delivery & assurance
- Ships from the UK
- UK & EU delivery, quoted with your price
- Pay by card or invoice
- Manufacturer's warranty
Questions about this product? Call our UK team: 023 9223 3611
Description
The EH2006 is an Ethernet switch with 6 RJ-45 ports for your industrial applications. These EH2006 has been designed for industrial environments, such as in hazardous locations where it complies with FCC, TUV, UL, and CE standards.
EH2006 protects itself from receiving too many broadcast packets. During normal use, broadcast packets will be forwarded to all ports except the source port. However, EH2006 will discard broadcast or multicast packets if the number of those packets exceeds a threshold in a preset period of time. When the preset period expires (about 800ms), it will then resume receiving broadcast or multicast packets until the threshold is reached again.
EH2006 series provide 2 redundant power inputs that can be connected simultaneously to wide-range DC power sources. If one of the power inputs fails, the other live source acts as a backup to provide the EH2006 power needs automatically.
EH2006 specifications
| Switch type | Unmanaged |
|---|---|
| Total number of ports | 6 |
| Fast Ethernet 10/100BaseT(X) | 6 |
| Fast Ethernet fibre ports (SFP, LC or ST) | None |
| PoE/PoE+ ports | None |
| Power input | 9~30 V |
| Power redundancy | Supported |
| Relay output | None |
| Housing | Plastic |
| Installation | DIN-Rail |
| Ingress protection | IP30 |
| Dimensions (L x W x H) | 45 x 90 x 80 mm |
| Operating temperature | 0~60° C |
| Storage temperature | -40~60° C |
| Compliance | UL/EN/IEC(CB) 60950-1 and/or 62368-1; EN60950-1 and/or EN62368-1 |
| Management protocols | None (no SNMP, VLAN, QoS, STP/RSTP or IGMP) |
Specifications taken from the manufacturer datasheet.
Which version do I need?
The EH2005 and EH2006 share one ATOP datasheet. The EH2006 is the all-copper option: 6 x 10/100BaseT(X) and no fibre. The EH2005 trades two copper ports for one fibre port (4 copper + 1 fibre). The aluminium-housed EH2306 is the same 6-copper layout with a wider -10~70°C operating range.
Complete the stack
Products that work with this one — connect it, power it, and get it online.
EH2006 — frequently asked questions
How many ports does the EH2006 have?
Six 10/100BaseT(X) copper ports. There is no fibre port on this model - if you need fibre, the EH2005 provides four copper ports plus one fibre port instead.
Does the EH2006 support PoE?
No. No PoE or PoE+ ports are listed on the EH2006, so powered devices will need a separate injector or a PoE switch.
Is it a managed switch?
No, it is unmanaged, with no SNMP, VLAN, QoS, STP/RSTP or IGMP support listed. There is no configuration interface.
What power supply does it need?
A 9~30 V supply, with redundant power input supported so a second supply can be wired in.
What temperature range does it tolerate?
0~60°C operating and -40~60°C storage. For colder or hotter installations the aluminium-housed EH2306 covers -10~70°C.
How much does the ATOP EH2006 Industrial Unmanaged Ethernet Switch cost in the UK?
The ATOP EH2006 Industrial Unmanaged Ethernet Switch is supplied to order and priced on application. Send a quote request and we confirm the price and lead time in writing, usually the same working day. No account is needed. Indiott is a UK distributor invoicing with VAT (PSI Technologies Ltd, VAT GB 730 2340 83).
What is the lead time and delivery cost for the ATOP EH2006 Industrial Unmanaged Ethernet Switch?
The ATOP EH2006 Industrial Unmanaged Ethernet Switch is supplied to order. We confirm the lead time in writing with your quote, before you commit to anything. UK delivery is a flat £14.25 per order ex VAT, whatever the weight or how many items you order. We ship to GB and the EU and provide a VAT invoice with every order.
