ATOP IJG7001 Industrial PoE Injector
Request a price
The IJG7001 is an industrial PoE injector that takes a dedicated 12 VDC input and boosts it to deliver up to 30 W of IEEE 802.3at PoE+ power across two 10/100/1000 BASE-T(X) ports. Use it to power an IP camera or wireless access point from a machine-side 12 VDC supply. Mode A and Mode B are DIP-switch selectable. Operating range is -40°C to +75°C.
PoE Voltage BoosterYes (max support 30W) from a 12 VDC input
● Quotes answered within one working day
Available to order · request a quote for price and lead time
Delivery & assurance
- Ships from the UK
- UK & EU delivery, quoted with your price
- Pay by card or invoice
- Manufacturer's warranty
Questions about this product? Call our UK team: 023 9223 3611
Description
The PG59XX Series is a highly reliable and fault tolerant Industrial Protocol Gateway. Its powerful architecture provides seamless conversion between the different protocols Ethernet or Serial based. The serial devices communicating on different protocols could be integrated into the system and extend its reach over the gateway’s redundant Ethernet. This device is designed to work in most demanding industries such as power substations, power generation, oil and gas, farming and manufacturing.
4-Port RS‑232/485/422 and 2× Fast Ethernet or Gigabit RJ45 protocol gateway. Supports DNP3.0, Modbus, IEC 60870‑5‑101/103/104 and IEC 61850.
IJG7001 specifications
| Ethernet ports | 2x 10/100/1000 BASE-T(X) (data in, data + PoE out) |
|---|---|
| PoE standards | IEEE 802.3af (PoE, max 15.4W); IEEE 802.3at (PoE+, max 30.0W) |
| PoE voltage booster | Yes (max support 30W) |
| PoE modes | Mode A / Mode B, DIP-switch selectable |
| Mode A pins | PoE power through data pins (1,2,3,6) |
| Mode B pins | PoE power through spare pins (4,5,7,8) |
| RJ45 transmission rate | 10/100/1000 Mbps |
| Auto MDI/MDI-X | Yes |
| Input voltage | 12 VDC (power limitations) |
| Input current | Max 3.6A @12VDC |
| Max. power consumption | 30W |
| LED indicators | P1, P2, PoE |
| Housing | IP30 metal housing |
| Dimensions (W x H x D) | 32 x 110 x 90 mm |
| Weight | 340g |
| Installation | DIN-Rail, wall mount (optional kit) |
| Operating temperature | -40°C to +75°C (-40°F to +167°F) |
| Storage temperature | -40°C to +85°C |
| Ambient relative humidity | 5% to 95% (non-condensing test @55°C) |
| Safety | EN60950-1, EN62368-1 |
| MTBF | 72.23 years |
| Warranty | 5 years |
Specifications taken from the manufacturer datasheet.
Which version do I need?
One model only: IJG7001, part number 1P1IJG70010001G (2 RJ45 ports, 0 SFP, 1 PoE port, 12V PoE booster). The aluminium wall-mount kit is a separate accessory, part number 70100000000052G.
Typical applications for the IJG7001
- Powering IP cameras from a machine-side 12 VDC supply
- Powering wireless access points
- Adding PoE to an existing industrial Ethernet switch link
- Powering legacy 802.3af devices where only PoE+ or only 12 VDC is available
- Machine-side installation to reduce power supply equipment cost
- Industrial network and IoT device deployments
Complete the stack
Products that work with this one — connect it, power it, and get it online.
IJG7001 — frequently asked questions
How much PoE power can the IJG7001 supply?
Up to 30.0 W per IEEE 802.3at (PoE+). It also supports legacy IEEE 802.3af (PoE) at a maximum of 15.4 W, so it will power either class of device.
What power supply does the injector itself need?
A dedicated 12 VDC input, drawing a maximum of 3.6 A at 12 VDC. Maximum power consumption is 30 W. The built-in PoE voltage booster raises the 12 VDC input to PoE+ output level.
Does it support both Mode A and Mode B PoE?
Yes, selected by DIP switch. Mode A delivers power through data pins 1, 2, 3 and 6; Mode B delivers power through spare pins 4, 5, 7 and 8.
Will it pass gigabit data through to the powered device?
Yes. There are two 10/100/1000 BASE-T(X) ports (data in, data plus PoE out) at 10/100/1000 Mbps with Auto MDI/MDI-X, compliant with IEEE 802.3, 802.3u and 802.3ab.
How is it mounted and what temperature range does it hold?
IP30 metal housing, 32 x 110 x 90 mm, 340 g, DIN-rail mounted with an optional aluminium wall-mount kit (70100000000052G). Operating temperature is -40°C to +75°C at 5% to 95% relative humidity, non-condensing.
How much does the ATOP IJG7001 Industrial PoE Injector cost in the UK?
The ATOP IJG7001 Industrial PoE Injector is supplied to order and priced on application. Send a quote request and we confirm the price and lead time in writing, usually the same working day. No account is needed. Indiott is a UK distributor invoicing with VAT (PSI Technologies Ltd, VAT GB 730 2340 83).
What is the lead time and delivery cost for the ATOP IJG7001 Industrial PoE Injector?
The ATOP IJG7001 Industrial PoE Injector is supplied to order. We confirm the lead time in writing with your quote, before you commit to anything. UK delivery is a flat £14.25 per order ex VAT, whatever the weight or how many items you order. We ship to GB and the EU and provide a VAT invoice with every order.
