Milesight TS601 cellular temperature and humidity sensor

TS601-L0DEU

Milesight TS601 Cellular Temperature Sensor

In stock UKMilesight

Where it sits in the stack

£74.82 ex VAT (£89.78 inc. VAT)

Cellular (LTE Cat.1) temperature sensor with built-in digital CMOSens probe

TS601 is a cellular LTE Cat.1 temperature and humidity sensor that measures with an integrated sensor and has no external probe connector — the decisive difference from TS602, which adds a 5-pin M12 connector for PT100, DS18B20 or TH probes and a 0.96-inch OLED. TS601 covers -35°C to +70°C, typically ±0.2°C between 0°C and 65°C, IP67.

Connector Type (external probe support)None — integrated sensor only. TS602 adds a 5-pin M12 A-coded male connector for TH/DS18B20/PT100 probes and a 0.96-inch OLED display

Not sure this is the right model?

In stock · typically dispatched within 14 working days from the UK

● Quotes answered within one working day · UK support

Delivery & assurance

Ships from the UK
£14.25 flat UK delivery
Secure checkout — card, Klarna, invoice
Manufacturer's warranty

Ships to the UK & EU · VAT invoice provided · Delivery & returns

Questions about this product? Call our UK team: 023 9223 3611

Solutions this product serves

Cold chain Smart buildings

Overview
Specifications

Description

The TS601 is a Milesight cellular temperature sensor — cellular (LTE Cat.1) temperature sensor with built-in digital CMOSens probe.

Key features

Cellular (LTE Cat.1) temperature sensor with built-in digital CMOSens probe
Temperature range -35C to +70C, accuracy to +/-0.2C
Approx. 4.8 years battery life on replaceable Li-SOCl2 cell
Single status LED; multi-layer sealing against condensation
Cold-chain monitoring: truck trailers, cargo crates, medical coolers

Supplied by Indiott, the UK industrial IoT specialists, with engineer-led support. Request a quote for pricing, stock and lead times.

Additional information

Weight	0.192 kg

TS601-L0DEU specifications

Temperature Range	-35°C to +70°C (integrated digital CMOSens MEMS sensor)
Temperature Accuracy	Typ. ±0.3°C (-35°C to 0°C), ±0.2°C (0°C to 65°C), ±0.5°C (65°C to 70°C)
Temperature Resolution	Report: 0.01°C, Display: 0.1°C
Humidity Range	0% to 100% RH
Humidity Accuracy	Typ. ±2% RH; resolution 0.1% RH
Connector Type	None on TS601 — the 5-pin M12 A-coded male connector for TH/DS18B20/PT100 probes is TS602 only
Screen	None on TS601 — the 0.96-inch OLED is TS602 only
LED	1 × Status Indicator (TS601 only) for device status and threshold alarms
Light Sensor	0 to 600 Lux, status Light/Dark (cargo box opening detection and alarm)
Device Position	Status Normal/Tilt; measurement range -90° to +90° on all X, Y, Z axes (3-axis accelerometer)
Base Station Positioning	Longitude/Latitude; typ. deviation 1 km, max deviation 5 km on urban main roads
Wireless Transmission Technology	LTE Cat.1
Frequency	LTE-FDD: B1/B3/B5/B7/B8/B20/B28 for EMEA + Australia/New Zealand
SIM Slot	1 × Nano SIM (4FF) slot, 1.8V/3V
Application Mode	TCP/UDP/MQTT/AWS/Milesight Development Platform
Min. Packet Transmission Interval	30 min @ operating temperature ≤0°C; 15 min @ operating temperature >0°C
Advanced Features	Threshold Alarm, Data Storage (5,000 entries), Data Retransmission; NFC configuration; flight mode
Power Supply	2 × 2500 mAh CR18505 Li-MnO2 batteries; 1 × Type-C port (internal) for power supply
Battery Life	MQTT/TCP around 4.8 years, AWS around 3.9 years, UDP around 5.1 years (6 reports/day, 8 packages per report, 30-min collection interval, positioning disabled, -20°C)
Enclosure / Environment	IP67; ABS+PC (food-grade), White; operating temperature -35°C to 70°C; 112 × 72 × 29 mm; 192 g with batteries

Specifications taken from the manufacturer datasheet.

Which version do I need?

TS601 is a cellular device, not LoRaWAN — it takes a nano SIM rather than connecting to a gateway, so the usual EU868 UK band note does not apply. The datasheet documents one radio variant, LTE-FDD B1/B3/B5/B7/B8/B20/B28 for EMEA + Australia/New Zealand, which covers UK networks. The -L0DEU suffix itself is not explained in the datasheet. The optional probes listed (PT100 SP11 series, DS18B20 SP12, TH SP13) attach to TS602 only.

Typical applications for the TS601-L0DEU

Cold chain transportation of food
Cold chain transportation of medicine
Cargo box opening detection and alarm
Asset tracking and security via base-station positioning
Temperature and humidity monitoring in harsh environments

Buying guides for this product

Fridge Temperature Monitoring →Vaccine Fridge Temperature Monitoring →Warehouse Temperature Monitoring →

Complete the stack

Products that work with this one — connect it, power it, and get it online.

Milesight Smart Building Occupancy Kit — Occupancy + Air Quality + Gateway
KIT-OCCUPANCY £531.21 ex VAT (£637.45 inc. VAT)
Add to basket
Milesight EG71 Building IoT Gateway
EG71-L08GL-868M £1,047.44 ex VAT (£1,256.93 inc. VAT)
Add to basket
Milesight LoRaWAN Starter Kit — Gateway + 3 Environmental Sensors
KIT-LORA-STARTER £619.49 ex VAT (£743.39 inc. VAT)
Add to basket
Milesight UG63 Mini LoRaWAN® Gateway
UG63 Price range: £98.76 through £131.68 ex VAT (£118.51 – £158.02 inc. VAT)
Select options This product has multiple variants. The options may be chosen on the product page

TS601-L0DEU — frequently asked questions

Does the TS601 have a display?

No. The 0.96-inch OLED is listed as a TS602-only feature. TS601 instead carries a status LED indicator to show device status and threshold alarms.

Can I connect an external probe to a TS601?

No. Connector Type is blank for TS601 — the 5-pin M12 A-coded male connector that accepts PT100, DS18B20 and TH probes is TS602 only. TS601 measures -35°C to +70°C with its integrated sensor.

Does the TS601 need a LoRaWAN gateway?

No. TS601 is cellular: LTE Cat.1 with a 1 × Nano SIM (4FF) slot at 1.8V/3V, on LTE-FDD bands B1/B3/B5/B7/B8/B20/B28. It reports over TCP, UDP, MQTT, AWS or the Milesight Development Platform.

How often can the TS601 report?

The minimum packet transmission interval is 15 minutes above 0°C and 30 minutes at or below 0°C, where the packet interval equals reporting interval × cumulative numbers. It stores 5,000 entries locally and supports data retransmission.

Is the TS601 safe to use with food or medicine?

The enclosure is food-grade ABS+PC and IP67-rated, and the datasheet states the enclosure allows safe contact with food or medicines. It also supports flight mode to comply with aviation safety requirements.

How much does the Milesight TS601 Cellular Temperature Sensor cost in the UK?

The Milesight TS601 Cellular Temperature Sensor is £74.82 ex VAT from Indiott, a UK distributor. The price is published rather than quote-only, and we invoice with VAT (PSI Technologies Ltd, VAT GB 730 2340 83). UK delivery is a flat £14.25 per order ex VAT, whatever the weight.

What is the lead time and delivery cost for the Milesight TS601 Cellular Temperature Sensor?

The Milesight TS601 Cellular Temperature Sensor is in stock and typically dispatched within 14 working days from the UK. UK delivery is a flat £14.25 per order ex VAT, whatever the weight or how many items you order. We ship to GB and the EU and provide a VAT invoice with every order.
