Milesight EM500-CO2 CO2 Sensor (4 in 1)
Authorised Milesight UK Distributor£179.56 ex VAT (£215.47 inc. VAT)
The Milesight EM500-CO2 is a battery-powered LoRaWAN sensor that measures carbon dioxide, temperature, humidity and barometric pressure in one IP65 enclosure. Its NDIR CO2 range is 400 to 5000 ppm with ± (30 ppm + 3% of reading) accuracy and 1 ppm resolution. A single replaceable 19000 mAh cell is rated for 10 years at a 10-minute reporting interval.
CO2 measuring range400 - 5000 ppm (NDIR), ± (30 ppm + 3% of reading)
In stock · typically dispatched within 14 working days from the UK
Kits that use this part: Cellar monitoring kit · Greenhouse monitoring kit · Poultry house monitoring kit
● Quotes answered within one working day · UK support
Delivery & assurance
- Ships from the UK
- £14.25 flat UK delivery
- Secure checkout — card, Klarna, invoice
- Manufacturer's warranty
Questions about this product? Call our UK team: 023 9223 3611
Description
EM500-CO2 is designed for measuring CO2, temperature, humidity and barometric pressure in harsh environments and
transmitting data using LoRaWAN® technology. With this low
power consumption technology, EM500-CO2 can work up to 10
years with 19000 mAh battery. Combining with Milesight
LoRaWAN® gateway and Milesight IoT Cloud solution, users can
manage all sensor data remotely and visually. EM500-CO2 is widely used for applications like smart agriculture, smart city, forest fire detection, etc.
• Features
• Integrated with multiple sensors like CO2, temperature, humidity, etc. • Ultra-wide-distance transmission up to line of sight of 10km
• IP65 waterproof enclosure for harsh environment applications
• Built-in 19000 mAh replaceable battery and work for 10 years
without replacement
• Equipped with NFC for easy configuration
• Compliant with standard LoRaWAN
® gateways and network
servers
• Quick and easy management with Milesight IoT Cloud solution
• Applications
• Warehouse environment
monitoring
• Basement and underground
parking monitoring
• Smart agriculture
• Forest fire detection
• Smart building
Additional information
| Weight | 0.43 kg |
|---|
EM500-CO2-868M specifications
| CO2 range | 400 - 5000 ppm |
|---|---|
| CO2 sensor type | NDIR |
| CO2 accuracy | ± (30 ppm + 3% of reading) (0°C - 50°C, 0 - 85% RH) |
| CO2 resolution | 1 ppm |
| Temperature | -30°C to +70°C; ± 0.3°C (0 to +70°C), ± 0.6°C (-30 to 0°C); 0.1°C resolution |
| Humidity | 0% to 100% RH; ± 3% (10-90% RH), ± 5% below 10% and above 90%; 0.5% RH resolution |
| Barometric pressure | 300 - 1100 hPa; ± 1 hPa; 0.1 hPa resolution |
| Wireless technology | LoRaWAN® |
| Frequency | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
| Tx power | 16 dBm (868 MHz) / 20 dBm (915 MHz) / 19 dBm (470 MHz) |
| Sensitivity | -137 dBm @300bps |
| LoRaWAN mode | OTAA/ABP Class A |
| Transmission range | Line of sight up to 10 km |
| Advanced features | Data storage (1,000 entries), data retransmission, data retrievability, threshold alarm, calibration |
| Configuration | Mobile app via NFC, PC software via USB Type-C, downlink |
| Power supply | 1 × 19000 mAh ER34615 Li-SOCl2 battery (replaceable) |
| Battery life | 10 years (10 min interval, 25°C) |
| Operating temperature | -30°C to +70°C |
| Relative humidity | 0% to 95% (non-condensing) |
| Ingress protection | IP65 |
| Dimensions / weight | 147.9 × 71 × 69.5 mm; 434.7 g (with battery and mounting bracket) |
| Installation | Pole, wall or DIN rail mounting |
| Approvals | CE, FCC, LoRaWAN® Certified, ISED, ICASA, Telec; EN62368-1; RoHS |
Specifications taken from the manufacturer datasheet.
Which version do I need?
The -868M suffix is the EU868 frequency build, which is the plan UK LoRaWAN networks use. The datasheet lists CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 and quotes 16 dBm transmit power at 868 MHz.
Typical applications for the EM500-CO2-868M
- Warehouse environment monitoring
- Basement and underground car park monitoring
- Smart agriculture
- Forest fire detection
- Smart building indoor air quality
Buying guides for this product
Frequency band
Supplied on EU868, the LoRaWAN band used in the UK and across Europe. That is the default and you do not need to ask for it — the -868M in the part number is the EU868 build.
The same EM500-CO2-868M unit also covers IN865 and RU864. Those bands share the 863–870 MHz radio with EU868, so one device can be set to any of them in its own configuration — no different part number needed.
CN470, US915, AU915, KR920 and AS923 are a different radio and therefore a different build. Milesight makes them and we can order them: tell us where the devices are being deployed and we will confirm the part number, price and lead time.
Not sure which band applies where? The Things Network publishes the LoRaWAN frequency plan for every country.
Complete the stack
Products that work with this one — connect it, power it, and get it online.
Which gateway do I need? Compare the Milesight range, from £98.76 →
-
Milesight Smart Building Occupancy Kit — Occupancy + Air Quality + Gateway
KIT-OCCUPANCY £531.21 ex VAT (£637.45 inc. VAT) -
-
Milesight LoRaWAN Starter Kit — Gateway + 3 Environmental Sensors
KIT-LORA-STARTER £619.49 ex VAT (£743.39 inc. VAT) -
Milesight UG63 Mini LoRaWAN® Gateway
UG63 Price range: £98.76 through £131.68 ex VAT (£118.51 – £158.02 inc. VAT)Select options This product has multiple variants. The options may be chosen on the product page
EM500-CO2-868M — frequently asked questions
What is the CO2 measuring range and accuracy?
400 to 5000 ppm using an NDIR sensor, accurate to ± (30 ppm + 3% of reading) between 0°C and 50°C at 0-85% RH, with 1 ppm resolution.
How long does the battery last and can it be replaced?
One replaceable 19000 mAh ER34615 Li-SOCl2 cell, quoted at 10 years with a 10-minute reporting interval at 25°C. That figure is tested under laboratory conditions and given for guideline purposes.
Can the EM500-CO2 be used outdoors?
Yes. The enclosure is IP65 waterproof and it is rated -30°C to +70°C at 0-95% RH non-condensing. It mounts on a pole, wall or DIN rail, and Milesight lists uses such as underground parking and forest fire detection.
Does it need a gateway?
Yes. It uses standard LoRaWAN in OTAA/ABP Class A with line-of-sight range up to 10 km, and works with standard LoRaWAN gateways and network servers as well as Milesight IoT Cloud and the Milesight Development Platform.
What happens if the network goes down?
It stores 1,000 entries locally and supports data retransmission and data retrievability, so readings taken while the link was down can be recovered once it returns. Threshold alarms and calibration are also supported.
How much does the Milesight EM500-CO2 CO2 Sensor (4 in 1) cost in the UK?
The Milesight EM500-CO2 CO2 Sensor (4 in 1) is £179.56 ex VAT from Indiott, a UK distributor. The price is published rather than quote-only, and we invoice with VAT (PSI Technologies Ltd, VAT GB 730 2340 83). UK delivery is a flat £14.25 per order ex VAT, whatever the weight.
What is the lead time and delivery cost for the Milesight EM500-CO2 CO2 Sensor (4 in 1)?
The Milesight EM500-CO2 CO2 Sensor (4 in 1) is in stock and typically dispatched within 14 working days from the UK. UK delivery is a flat £14.25 per order ex VAT, whatever the weight or how many items you order. We ship to GB and the EU and provide a VAT invoice with every order.
